Folding Window Opener

  • Window Type: Casement windows (side‑hung, inward & outward opening)
  • Drive Type: Chain drive
  • Control: Manual / Electric / Remote / APP control
  • Stroke: 100–600mm (customizable)
  • Force: 200–1200N
  • Voltage: DC 24V (safe standard)
  • Protection: IP30–IP65 waterproof & dustproof
  • Material: Aluminum alloy + engineering plastic
  • Life: ≥10,000 opening cycles
  • Safety: Anti-pinch overload protection, fire linkage compatible
  • Application: Home, office, hotel, sunroom, smoke ventilation

Performance

🔧 1. Powerful & Reliable Drive

Equipped with a high-torque DC motor, delivering a maximum pushing force of 800N. Easily handles large casement windows or older, high-resistance windows with smooth opening and closing, even in windy or rainy conditions.


🔇 2. Ultra-Quiet Operation

Precision gearbox and shock-absorbing structure keep operating noise at ≤45 dB — quieter than a library. Perfect for bedrooms, nurseries, and study rooms. Enjoy automated ventilation without disturbing your daily life or sleep.


🌧️ 3. All-Weather Durability

Rated IP65 dustproof and waterproof, featuring weather-resistant housing and sealed rubber gaskets. Withstands sun, rain, and extreme temperatures. The motor is rigorously tested for 20,000+ open/close cycles, ensuring a 10+ year service life under normal use.


🛡️ 4. Smart Obstruction Detection

Built-in high-sensitivity current sensing chip detects obstacles (such as curtains or hands) during operation. The system stops and reverses within 0.1 seconds, protecting people, windows, and the device from damage.


📱 5. Smart Home Integration

Supports Wi-Fi, Zigbee, and dry contact control options. Compatible with major smart home platforms including Alexa, Google Home, and Mi Home. Set schedules, auto-close when it rains, or control remotely — intelligent living at your fingertips.

Application

🏡 Smart Home

Integrate with temperature, humidity, and CO₂ sensors for automatic ventilation. Set schedules or trigger rain-auto-close — enjoy a truly intelligent living experience.


🏥 Medical & Senior Care

Low-noise operation and anti-pinch safety design make it ideal for hospitals, nursing homes, and assisted living facilities. Provides fresh air without disturbing rest.


🏭 Commercial & Industrial

High thrust capacity and durable construction suitable for factories, warehouses, greenhouses, and large commercial casement windows. Built for continuous, heavy-duty use.


🏠 Residential & Villas

Sleek, minimalist design blends seamlessly with modern architecture. Enhances home comfort, security, and energy efficiency with automated ventilation.


🌿 Green Buildings

Supports energy-efficient ventilation strategies. Helps maintain indoor air quality while reducing HVAC load — ideal for LEED-certified and passive house projects.

Specifications

Parameter Specification
Product Name Electric Casement Window Opener
Push / Pull Force 800N / 600N
Stroke Length 300mm – 500mm (customizable)
Operating Speed 10 – 14 mm/s
Voltage DC 24V
Rated Power 48W
Protection Rating IP65
Noise Level ≤45 dB
Operating Temperature -20℃ ~ +75℃
Motor Type Brushless DC Motor
Control Options Wired Switch / Remote / Smart Module
Certifications CE / RoHS / FCC
